1400DPH HVOF 0.3mm Coating Tungsten Carbide Plating

1400DPH HVOF 0.3mm Coating Tungsten Carbide Plating
Features Gallery Product Description Request A Quote
Features
Specifications
Tungsten Carbide Powder: American Praxair 1342 Super-hard 1342 Tungsten Carbide Powder
Workpiece Shape: Cylinder
Coating: 0.05-0.3mm Or Customized
Plating Technology: HVOF
Plating Equipment: American Praxair JP8000
Polishing: Customized
High Light:

0.3mm Coating Tungsten Carbide Plating

,

1400DPH Tungsten Carbide Plating

,

Ra0.2 HVOF Tungsten Carbide Plating

Basic Infomation
Place of Origin: China
Brand Name: YH
Certification: ISO9001
Payment & Shipping Terms
Packaging Details: Wooden case
Delivery Time: 30-45days
Payment Terms: T/T
Supply Ability: 500㎡
Product Description

Specialty of HVOF Tungsten Carbide Plating



1. Accelerate partical effectively without superheat phenomenon.

2. Low degree of oxidation using tungsten carbide as original material, the loss of carbon close to vaccum spraying

3.Porosity<1%

4. Intensity close to sintered/founding material

5. High hardness, high binding force, high abradability

6. Excellent performance of polishing

7. Low residual stress, unlimited coating thickness

8. High production efficiency, intelligent, automatical machine without spraying blind cornor

9. No accumulated burl in the process of spraying.



Item   Result
 Thickness of coating  Within 4 mm
Adhesion  More than 10000psi
Porosity Less than 1%
Oxide Less than 2%
Hardness of Coating  1400DPH
Smooth Finish Less than Ra 0.2-0.8 or customized
